Internal (Bore) Grinding Machine
Internal (Bore) Grinding Machine
Devco offers Internal (Bore) Grinding Machine, HIC-150.
Optional accessories:
- Two point steady rest
- Three point steady rest
- True chuck & dog chuck
Model HIC-150
- Distance between centre: 160 mm
- Height of centre: 102 mm
- Swiveling angle: ±9º
- Traverse speed: 140-260-370-700 mm/min
- In feed of hand wheel: 0.01 division
- Grinding wheel speed: 12000 rpm
- Work head spindle speed: 90-210-360 rpm (three range)
- Spindle in taper: MT-3
- Casting are close grained and well ribbed
- Minimize vibration and distortion; internal spindle runs in bearings
- Work head spindle runs in taper roller bearing
- Tail stock
- Wheel head and work head spindle are heat treated to achieve dimensional stability
- Performance roundness<0.005 mm
