Centrifugal pumps, vertical multi-stage

Fivebro Water Services offers Centrifugal pumps in vertical multistage in line construction. These pumps are durable with efficient hydraulic design, have inline suction and discharge connection, expansion free radial sleeve sealing; mechanical shaft seal; and all wetted parts in stainless steel. Duty range: capacity - up to 75 m3/hr; head - up to 220 m; maximum working pressure - 2500 kpa; temperature range - 20 to +120?C; max ambient temperature - 50?C. Features: The design of SS diffuser reduces internal losses which improves the efficiency of the pump; SS pump shaft with flat faces make strong shaft/impeller construction; suction discharge casing with separate base plate enables special corrosion resistance treatments; the entire housing is made of stainless steel; shaft bearing through combination of tungsten carbide bearing on shaft and ceramic bearing in diffuser; tie rods are made of SS for maximum resistance against corrosion caused by environmental influences; spring loaded DIN seal with bellow construction and the fit to purpose material combinations offer long life; and for models with heavy motors, a cartridge version is provided, which enables seal-exchange without removing the motor.
